AUTO ASPIRING WALL HOOD WITH LABYRINTH FILTER AND GABLED OUTLINE
AISI 304 stainless steel through spot-welding with satin finish. Digital control panel with speed variator. Shaped sealing joint with tap for recovery of condensed fats. Equipped with accessories for fastening and 2 labyrinth filters in AISI 304 stainless steel.
| Air capacity | m³/h 1400 |
| Hst | mm H2O 18 |
| Positioning | wall mounted |
| Depth | 110 cm |
| Working voltage | 230V 1N~ / 50 ÷ 60Hz |
| Net Weight | 42 kg |
| Gross Weight | 66 kg |
| Packing Width | 130 cm |
| Packing Height | 55 cm |
| Packing Depth | 127 cm |
| Width | 120 cm |
| Height | 45 cm |
| Depth | 110 cm |
| Electric Power | 0,184 kW |
| Electric supply height | 260 cm |
| Dimensions | 120x110x45 cm |
| Packing | 130x127x55 cm |
