BAIN MARIE WELL ON OPEN CUPBOARD - 3 GN
Pressed well 210 mm deep with rounded corners , endowed with bridge-bars to hold containers, capacity n.3 GN 1/1. Water functionning +30 +90 °C; manual loading though the switch on the control board. Independent digital temperature controls. Endowed with operating and safety thermostat. Top in AISI 304 stainless steel, 1,5 mm thick. Lower cupboard: neutral open version. The block must necessarily be completed with paneling, choosing the type of panel preferred.
| Capacity | 3 GN |
| Working voltage | 230V 1N~ / 50 ÷ 60Hz |
| Net Weight | 77 kg |
| Gross Weight | 85 kg |
| Packing Width | 125 cm |
| Packing Height | 108 cm |
| Packing Depth | 88 cm |
| Width | 120 cm |
| Height | 90 cm |
| Depth | 83 cm |
| Electric Power | 2,1 kW |
| Electric supply height | 15 cm |
| Hot water diameter | 3/4 |
| Hot water connection height | 15 cm |
| Water drain diameter | 3/4 |
| Water drain height | 15 cm |
| Dimensions | 120x83x90 cm |
| Packing | 125x88x108 cm |
