BAIN MARIE WELL ON OPEN CUPBOARD - 6 GN
Pressed well 210 mm deep with rounded corners , endowed with bridge-bars to hold containers, capacity n.6 GN 1/1. Water functionning +30 +90 °C; manual loading though the switch on the control board. Independent digital temperature controls. Endowed with operating and safety thermostat. Top in AISI 304 stainless steel, 1,5 mm thick. Lower cupboard: neutral open version. The block must necessarily be completed with paneling, choosing the type of panel preferred.
| Capacity | 6 GN |
| Working voltage | 400V 3N ~ 50 ÷60 Hz |
| Net Weight | 97 kg |
| Gross Weight | 107 kg |
| Packing Width | 235 cm |
| Packing Height | 108 cm |
| Packing Depth | 88 cm |
| Width | 230 cm |
| Height | 90 cm |
| Depth | 83 cm |
| Electric Power | 3,5 kW |
| Electric supply height | 15 cm |
| Hot water diameter | 3/4 |
| Hot water connection height | 15 cm |
| Water drain diameter | 3/4 |
| Water drain height | 15 cm |
| Dimensions | 230x83x90 cm |
| Packing | 235x88x108 cm |
